Team levelup
Rosenheim Technical University of Applied Sciences
Team
ID
ROS
Team Name
Team levelup
University
Rosenheim Technical University of Applied Sciences
Public
true
Project is still active
true
Location
Home Location
90403 Nürnberg, Deutschland
Location after Competition
83024 Rosenheim, Deutschland
Tags
Project dimensions
Gross Area
81
m²
Net Floor Area
118
m²
Conditioned Volume
157
m³
Total Envelope Area
286
m²
House Envelope
Walls Thermal Transmittance
0,11
W/m²·K
Floor Thermal Transmittance
0,12
W/m²·K
Roof Thermal Transmittance
0,06
W/m²·K
Window Thermal Transmittance
0,5
W/m²·K
Glazing Thermal Transmittance
0,4
W/m²·K
Glazing Solar Heat Gain Coefficient
0,33
%
Glazing Visual Transmittance
0,63
%
HVAC System
Heating System Type
radiant heating (floor)
Heating Capacity
0,749
kW
Heating COP
4,3
Cooling System Type
radiant heating (floor)
Cooling Capacity
0,78
kW
Refrigerant
water
Ventilation Type
mechanical ventilation with heat recovery
Ventilation Capacity
120
m³/h
Specific Fan Power
0,33
W/(m³/h)
Degree of Heat Recovery Efficiency
79
%
Domestic Hot Water
System Type
decentral
Solar Thermal Aperture Area
18,76
m²
PV System
Module Type
mono crystalline
Number of Modules
39
Module Area
59,66
m²
Installed PV Power
3
kW
Nominal PV Power(Peak)
3,75
kWp
Estimated Energy Generation Home Climate
2505
Battery Type
cobalt-free lithium irion phosphate
Battery Capacity
2,5 kWh
Total End Energy Demand
Total Energy Demand Event
3198
kWh/a
Specific Energy Demand Event
53,3
kWh/a
Energy Demand Characterization Home
Net Energy Heating
1434
Net Energy Cooling
12
End Energy Heating
266
End Energy Heating
8,4
%
End Energy Cooling
0
End Energy Cooling
0
%
End Energy Ventilation
159
End Energy Ventilation
4,9
%
End Energy Domestic Hot Water
658
End Energy Domestic Hot Water
20,6
%
End Energy Lighting
924
End Energy Lighting
28,9
%
End Energy Appliances and Devices
1182
End Energy Appliances and Devices
36,9
%
End Energy Auxilliaries
9
End Energy Auxilliaries
0,3
%
